CSI Spiral Drive Pins are designed for permanently fastening a fixture to concrete, concrete over steel deck, concrete masonry walls and A36 or A572 / A992 structural steel. The fasteners are manufactured with an 8mm head and 0.157" diameter shank in various lengths; a 0.145" diameter tapered shank with 1/2-inch length is also available. A spiral knurled shank design provides consistent optimized performance in steel base materials. For single fasteners, a plastic washer is mounted on the pin shank to retain the drive pin in the barrel of the tool and provide centered guidance during the driving operation. The fasteners are also available in collated strips.

FEATURES & SPECS

SPECIFICATIONS

CATALOG NUMBER	SHANK DIAMETER	SHANK LENGTH	SHANK TYPE	PACK QTY
50238N-PWR	0.145"	1/2" (13MM) (K)	TAPERED	100
51450-PWR	0.157"	5/8" (16MM) (K)	STRAIGHT	100
50452-PWR	0.157"	3/4" (19MM) (K)	STRAIGHT	100
50454-PWR	0.157"	7/8" (22MM) (K)	STRAIGHT	100
50456-PWR	0.157"	1" (27MM) (K)	STRAIGHT	100
50458-PWR	0.157"	1-1/4" (32MM) (K)	STRAIGHT	100
50460-PWR	0.157"	1-1/2" (37MM) (K)	STRAIGHT	100
50461-PWR	0.157"	1-5/8" (42MM) (K)	STRAIGHT	100
50462-PWR	0.157"	2" (52MM) (K)	STRAIGHT	100
50463-PWR	0.157"	2-1/2" (62MM) (K)	STRAIGHT	100
