This 316 Stainless Steel Wedge-Bolt anchor from Powers Fasteners is a one piece, heavy duty screw anchor with a finished hex head. It is simple to install, easy to identify, fully removable and vibration resistant. The steel threads along the anchor body self tap into the hole during installation and provide positive keyed engagement.
Features and Benefits:
- High corrosion resistance
- Consistent performance in high and low strength concrete
- Anchor can be installed through standard fixture holes
- Can be installed with an impact wrench or conventional hand socket
- Finished hex head provides attractive appearance and minimizes tripping hazard
- Can be installed closer to the edge than traditional expansion anchors
- Ratchet teeth on underside of hex washer head lock against the fixture and increase vibration resistance
- Removable
General Applications and Uses:
- Interior and Exterior Applications
- Support ledges and windows
- Railing and fencing
- Storage facilities
- Repairs, maintenance & retrofits
Approvals And Listings:
- Tested in accordance with ASTM E488, AC106 criteria and AC193 criteria
Suitable Base Materials:
- Normal-weight concrete
- Grouted Concrete Masonry (CMU)
- Brick Masonry
Notes:
- Not suitable for chloride/chlorine environments
- 316 Stainless Steel Wedge-Bolt screw anchors are designed to be used with a matched tolerance Wedge-Bit for optimum performance.
