Description
-
- Very handy and manoeuvrable cordless sheet-metal shears for burr-free cutting of sheet metal on site
- Maximum cornering ability, for comfortable cutting of narrow radii from 15 mm
- Faster working, thanks to the efficient brushless motor
- Infinitely adjustable cutting speed for individual customisation to the given material and task at hand
- Comfortable handling thanks to low weight, slim grip area and switch located on the top
- Blade spacing can be flexibly adjusted to different sheet thicknesses
- Economical four-way reversible blade, with the highest cut quality
- Maximum safety in every cutting direction, thanks to large hand guard
- Electronic overload protection for long service life
- Many brands, one battery pack system: This product can be combined with all 18V battery packs and chargers of the CAS brands: www.cordless-alliance-systems.com
The machine shown may differ in equipment and technical details depending on the configuration.
Kindly pay attention to delivery scope and product description.
Accessories included only if listed in the delivery scope.
Characteristics
Type of battery pack
Li-Power
Battery voltage
18 V
Max. sheet thickness for steel: 400 N/mm²
1.6 mm / 0.0629 "
Max. sheet thickness for steel: 600 N/mm2
1.2 mm / 0.0472 "
Max. sheet thickness for steel: 800 N/mm2
0.7 mm / 0.0275 "
Max. sheet thickness for aluminium: 250 N/mm2
2 mm / 0.0787 "
Strokes in idle
1350 - 4840 rpm
Cutting speed
7 m/min // 275 inch/min
Starting hole diameter
27 mm / 1.0629 "
Smallest curve radius
15 mm / 0.5905 "
Weight without battery pack
1.4 kg / 3.1 lbs
Weight with battery pack
1.8 kg / 4 lbs
Vibration
Cutting of sheets
7.6 m/s²
Uncertainty of measurement K
1.5 m/s²
Noise emission
Sound pressure level
74 dB(A)
Sound power level (LwA)
85 dB(A)
Uncertainty of measurement K
3 dB(A)
